ISC Cast Pulley

£93.60£152.40

Clear

Earn up to 152 Reward Points.

SKU: IS-RP05 Category:

Description

ISC Cast Pulley – IS-RP05

Now manufactured using Hot Forging Technology combined with high quality materials and components these blocks are rope friendly, durable and extremely robust. All these features combined give maximum security and strength when the block is rigged as part of an impact system.

Apart from just the aesthetic curves the ISC Impact Pulley/Block is designed to help absorb huge forces along with the textiles created by the harsh dynamics of heavy arborist work.  The side plates are produced using the best quality hot forged Aluminium and in the special manufacturing process adopted by ISC allows these pulleys to boast great strength and dynamic load bearing capability and offer a highly impressive strength to weight ratio.

  • ISC trusted and proven spring-lock closure mechanism
  • Corrosion resistant anchor pin
  • Rounded edges maintain low rope abrasion
  • Highly impressive strength to weight ratio
  • Great strength and dynamic load bearing capability
  • High efficiency self-lubricating bushings to reduce friction
  • Conforms to EN 12278:2007
  • CE certification to European Machinery Directive 2005
  • Individually marked for trace-ability

ISC Mini Cast Pulley for 13 mm Rope Specifications:

  • Length – 125 mm
  • Width – 13 mm
  • Height – 76 mm
  • Weight – 490 g
  • Cheek Actions – Swing
  • Cheek Material – Cast Aluminium
  • Wheel Material – Aluminium
  • Min Breaking Strength – 85 kN
  • Working Load Limit – 17 kN
  • Approved Standards – CE
  • Finish – Green Powder Coated
  • Quality – 100% Inspected and Proof Tested
  • Serial Number – Individual Numbering

ISC Small Cast Pulley for 13 mm – 16 mm Rope Specifications:

  • Length – 182 mm
  • Width – 100 mm
  • Height – 100 mm
  • Weight – 1418 g
  • Cheek Actions – Swing
  • Cheek Material – Cast Aluminium
  • Wheel Material – Aluminium
  • Min Breaking Strength – 100 kN
  • Working Load Limit – 20 kN
  • Approved Standards – CE
  • Finish – Powder Coated
  • Quality – 100% Inspected and Proof Tested
  • Serial Number – Individual Numbering

ISC Medium Cast Pulley for 16 mm – 20 mm Rope Specifications:

  • Length – 220 mm
  • Width – 125 mm
  • Height – 100 mm
  • Weight – 2006 g
  • Cheek Actions – Swing
  • Cheek Material – Cast Aluminium
  • Wheel Material – Aluminium
  • Min Breaking Strength – 150 kN
  • Working Load Limit – 30 kN
  • Approved Standards – CE
  • Finish – ISC Red Powder Coated
  • Quality – 100% Inspected and Proof Tested
  • Serial Number – Individual Numbering

ISC Large Cast Pulley for 20 mm Rope Specifications:

  • Length – 258 mm
  • Width – 160 mm
  • Height – 100 mm
  • Weight – 3432 g
  • Cheek Actions – Swing
  • Cheek Material – Cast Aluminium
  • Wheel Material – Aluminium
  • Min Breaking Strength – 200 kN
  • Working Load Limit – 40 kN
  • Approved Standards – CE
  • Finish – Polished
  • Quality – 100% Inspected and Proof Tested
  • Serial Number – Individual Numbering
