Husqvarna 560 XP Chainsaw


SKU: 9660091 Category:

Enquire about machine hire

  • This field is for validation purposes and should be left unchanged.


Husqvarna 560 XP Chainsaw

The Husqvarna 560 XP® petrol chainsaw is developed for professional loggers and skilled land owners. This heavy duty chainsaw has a ground breaking design and is loaded with innovative solutions for efficient, convenient operation. This easy start chainsaw helps increase productivity, while the Husqvarna X-Torq engine helps provide more power when you need it, using up to 20% less fuel while producing 75% less exhaust emissions versus other professional chainsaws. RevBoost™ provides an instant high chain speed for extra efficient de-limbing in the toughest conditions. Supplied with interchangeable 15″ chainsaw bar as standard.


  • Cylinder displacement 59.8 см³
  • Standard Handle type
  • Weight (excl. cutting equipment) 5.9 kg
  • 2 Years Warranty
  • AutoTune gives optimal engine performance throughout automatic engine setting. No time spent on carburettor adjustments. It compensates for different fuels, altitude, humidity, temperature and clogged air filter.
  • Deliver lower fuel consumption and reduced exhaust emission levels in accordance with the world´s most stringent environmental regulations.
  • Rapid acceleration and higher chain speed for best limbing performance.
  • Centrifugal air cleaning system for reduced wear and longer operating time between filter cleanings.


  • Engine
    • Power output 3.5 kW
    • Cylinder displacement 59.8 см³
    • Maximum power speed 9600 rpm
    • Idling speed 2800 rpm
    • Torque, max. 3.65 Nm
    • Torque, max. at rpm 8100 rpm
    • Clutch engagement speed (±120) 4300 rpm
    • Fuel consumption 494 g/kWh
    • Fuel consumption 1.74 kg/h
    • Spark plug NGK CMR6H
    • Electrode gap 0.5 mm
    • Ignition module air gap 0.3 mm
    • Oil pump type Adjustable flow
    • Oil pump capacity Max 15 ml/min
    • Oil pump capacity Min 6 ml/min
    • Exhaust emissions (CO2 EU V) 777 g/kWh
  • Equipment
    • Recommended bar length, max 20 in
    • Recommended bar length, min 13 in
    • Chain speed at max power 21.3 m/s
    • Chain speed at 133% of maximum engine power speed 28.3 m/s
  • Dimension
    • Weight (excl. cutting equipment) 5.9 kg
  • Lubricant
    • Oil tank volume 0.33 l
    • Oil pump type Adjustable flow
    • Oil pump capacity Max 15 ml/min
    • Oil pump capacity Min 6 ml/min
  • Sound and Noise
    • Sound power level, guaranteed (LWA) 118 dB(A)
    • Sound power level, measured 116 dB(A)
    • Sound pressure level at operators ear 106 dB(A)
  • Vibration
    • Equivalent vibration level (ahv, eq) front handle 4.4 m/s²
    • Equivalent vibration level (ahv, eq) rear handle 5.3 m/s²
